FU807B型全自动高精度磨皮辊机

● 产品用途  ：PRODUCTUSES

该机器采用全新设计理念改变了传统磨胶辊机的繁锁操作方法，能使胶辊磨砺更加方便快捷、磨削******光洁。本机采用全自  动工作流程， PLC 全程控制，砂轮定量自动修整、皮辊大小自动检测、胶辊表面粗糙度自行设置，使皮辊达到******工作状  态，给纺纱带来更高品质。在皮辊磨削模式方面，有指定直径磨削、不同直径磨削和皮辊自动分拣三种模式可自行设定，这样能使皮辊使用周期更长，节约使用成本、提高工厂效益。

The machine adopts a new design concept to change the traditional roller grinding machine complex locking operation method,can make the roller  sharpening more convenient and fast,grinding precision and clean.The machine adopts automatic worktlow,PLC control,automatic quantitative grinding wheel dressing,roller size automatic detection,roller surface roughness self-setting,so that the roller to achieve the best working state,to bring higher quality spinning.In terms of roller grinding mode,there are three modes of designated diameter grinding,different diameter grinding and roller automatic sorting,which can be set by themselves,which can make the roller service cycle longer,save the use cost and improve the factory  efficiency

● 性能特征  ：CHARACTERISTICS

FU807B   型全自动磨皮辊机是在FU807A  型磨机基础上，设置加装全自动上下料大储料箱，每小时可磨砺500只皮辊，减少劳动用工、提高工作效率。

FU807B automatic roller grinding machine is based on FU807A mill,equipped with automatic loading and unloading large storage box,can sharpen

500 roler per hour,Reduce labor use and improve work eficency.

● 主要技术参数：MAIN TECHNICAL PARAMETERS

1、 自动检测，全程电脑操控

2、 磨削精度高，大小头小于0.02mm

3、 磨削胶辊表面粗糙度值******可达Ra0.4um

4、 每小时磨削胶辊最多可达350套

5、 砂轮自动修磨、自动清理

6、 胶辊自动上下料，大容量存储料箱

7、 料架容量：280套(430mm)

8、 额定功率：5.5kw

9、 机器重量：1300kg

10、 机器尺寸：4.0mx0.8m×1.6m

1,automatic detection,full computer control

2,high grinding accuracy,the size of the head is less than 0.02mm

3.grinding roller surface roughness value can reach the lowest Ra0.4um 4,grinding roller up to 350 sets per hour

5,grinding wheel automatic grinding,automatic cleaning

6,roller automatic loading and unloading,large capacity storage box 7.Material rack capacity :280 sets(430mm)

8,rated power :5.5kw

9.Machine weight :1300kg

10,machine size :4.0mx0.8m×1.6m
